Product

ST11-Q3

$0

Android flagship rugged tablet for multiple industries: Android 13 + Qualcomm 5G octa-core, large storage, 10.1-inch high-brightness HD screen, dual-battery all-day life. 5G/WiFi 6, IP65 protection + drop resistance for tough scenes. Built-in cooling, customizable—hardcore for logistics/finance pro work.

  • Buy Now
  • Add to shopping cart
In Stock:

Product Overview

The ST11-Q3 is a 10.1-inch rugged tablet powered by Qualcomm 5G SOC QCM4490 octa-core processor (2×Kryo [email protected] + 6×Kryo [email protected]), running Android 13 system. It features 8GB/128GB storage (4GB/64GB or 8GB/256GB optional), 10.1-inch 1200×1920 IPS display (450nits), 8MP front/16MP rear cameras with flash light, dual battery design (12000mAh main + 2400mAh secondary) with 22W fast charging, 5G connectivity, WiFi 6, Bluetooth 5.2 and NFC. With IP65 dust/waterproof, 1.2m drop resistance and MIL-STD-810G certification, it's optimized for 5G-enabled industrial IoT applications.

Key Features

  • Android 13 system, Qualcomm 5G SOC QCM4490 octa-core processor (2×Kryo [email protected] + 6×Kryo [email protected])
  • Adreno GPU 613, 10.1-inch 1200×1920 IPS display (450nits), 10-point touch with stylus & wet hand support
  • 8GB/128GB storage (4GB/64GB or 8GB/256GB optional), dual battery (12000mAh+2400mAh) with 22W fast charging
  • 8MP front + 16MP rear cameras with flash light, rich sensor suite including gyroscope and pressure sensor
  • 5G multi-band connectivity (SRM700 module), WiFi 6, Bluetooth 5.2 and NFC 13.56MHz
  • IP65 dust/waterproof, 1.2m drop resistance, MIL-STD-810G, CE, FCC, 3C certification
  • Rich interfaces including Type-C, USB 2.0, RJ45, RS232, TF card slot and dual pogopin connectors
  • Optional UHF RFID (M-500/M-301), 1D/2D barcode scanner (Honeywell N4680) and fingerprint (AFM60)

Technical Specifications (ST11-Q3)

OS Android 13
CPU Qualcomm 5G SOC QCM4490 (Octa Core; 2.4GHz)
Kryo Gold×2 @2.4GHz, Kryo Silver×6 @1.95GHz
GPU Adreno GPU 613
RAM/ROM 8GB/128GB
4GB/64GB Optional, 8GB/256GB Optional
LCD 10.1 inch; 1200×1920; 450nits; IPS
Touch Screen 10 Point Touch
Stylus Support; Wet Hand Touch Support
Camera Front: 8MP; Rear: 16MP (Flash light)
Power and Battery Main battery: 12000mAh / 3.8Vdc (45.6Wh)
Secondary battery: 2400mAh
Support 22W fast charging
WWAN 5G-FDD: N1/N3/N5/N7/N8/N20/N28
5G-TDD: N38/N40/N41/N77/N78/N79
LTE-FDD: B1/B3/B5/B7/B8/B20/B26/B28
LTE-TDD: B38/B40/B41
WCDMA: B1/B5/B8
Module: SRM700
GPS BDS, GPS, GLONASS, Galileo
WIFI 802.11a/b/g/n/ac/ax Wireless Internet; Wireless AP (Mobile AP); 2.4G, 5G; Support WiFi6
BLUETOOTH 5.2 Version
NFC 13.56 MHz, Distance: 1-3cm; ISO/IEC 14443A/B; ISO/IEC 15693
MIC Sensitivity: -32±2d; Output Impedance: 2.2kΩx1
SPEAKER 8Ω 1.5 Watt
Sensor Light sensor, Magnetic sensor, Pressure sensor, G-sensor, Distance sensor, Acceleration sensor, Gyroscope, Motor
Size 268.9×176.8×18mm
Weight 1140±50g
Language Multi language
Interface In/Out Port Type-C *1 (OTG); SIM Card Slot*1; TF Card Slot*1; Earphone*1; DC*1 (3.5×12mm); USB 2.0 *1; RJ45*1; RS232*1
Bottom pogopin: USB 2.0; Charging; RS232
Back pogopin: USB 2.0; RS232
Button V+ -, Power, "F" for Barcode Scan
Customized Button: P,H (Default No Functionality)
1D/2D Barcode Optional: Honeywell N4680 Optional
UHF RFID M-500 Optional
American standard M-500 (902Mhz – 928Mhz): External (3-5M)
European standard M-500 (865MHz – 868MHz): External (3-5M)
M-301 Optional
American standard M-301 (902Mhz – 928Mhz): External (5-8M)
European standard M-301 (865MHz – 868MHz): External (5-8M)
Fingerprint Optional: AFM60 Optional
Accessories Blue Box; DC Charger (5V 3A); Carry strap; Screw; Wrist strap; Screwdriver
Optional: Docking Station; Car Holder STA15; Car Holder STA03; Magnetic Keyboard
Multi-Media (Hardware Decoding) Photo Viewer: BMP, JPG, GIF, PNG
Video Format: MEPG 1/2/4, H.263/H.264, RMVB, WMV/VC-1, MVC, AVS, MJPEG (UP TO 1080P)
Audio Format: MP3, WMA, WAV, OGG, FLAC, ALAC, APE, AAC, AC-3, DTS (need license)
Proof Degree IP65 Anti-dust & Waterproof, 1.2m Dropping Resistance
Certification MIL-STD-810G; CE, FCC, 3C
Temperature Storage Temperature: -40°C to 60°C; Operation Temperature: -20°C to 55°C

Application Scenarios

📡
5G Industrial IoT
🏭
Smart Manufacturing
📦
Intelligent Warehousing
🌐
Remote Monitoring Systems
