SM5-T

$0

This high-performance, cost-effective Android 13 industrial-grade rugged terminal features a Unisoc octa-core processor, a 5.7-inch screen, a 4000mAh battery, and supports 4G/WiFi/BeiDou positioning.It boasts IP65 protection and 1.5-meter drop resistance, a wide temperature range of -25℃ to 50℃, expandable memory, and an affordable price, making it suitable for logistics, pharmaceutical, and warehousing applications.

  • Buy Now
  • Add to shopping cart
In Stock:

Product Overview

The SM5-T is a 5.7-inch rugged handheld terminal running Android 13.0, powered by Unisoc T616 octa-core processor (2.0GHz, T606 optional) with Mali-G57 MP1 GPU. It features dual storage options (4+64GB/8+128GB), 5.7-inch 720×1520 display (400nits), 5MP front/13MP rear cameras with flash, 4000mAh 3.8V battery, 4G LTE global connectivity, and dual microphones with noise reduction. With IP68 dust/waterproof, 1.5m drop resistance, 7-in-1 sensor suite, and compact design (155×77.7×13.3mm/230g), it's optimized for lightweight Android mobile data collection in harsh environments.

Key Features

  • Android 13.0 system, Unisoc T616/T606 octa-core processors (2.0GHz) with Mali-G57 MP1 GPU
  • Dual storage configurations (4+64GB/8+128GB) for flexible Android application support
  • 5.7-inch 720×1520 display (400nits), 5-point touch with stylus support for precise input
  • 13MP rear camera with flash, dual microphones (main + noise reduction) for clear communication
  • 4G LTE multi-band connectivity, dual SIM support (single standby), WiFi 5 and Bluetooth 5.0
  • IP68 dust/waterproof, 1.5m drop resistance, 7-in-1 sensor suite for harsh environment adaptability
  • Compact lightweight design (155×77.7×13.3mm/230g) with SOS emergency button
  • NFC 13.56MHz, Type-C OTG, bottom pogopin interface for versatile expansion

Technical Specifications (SM5-T)

OS Android 13.0
CPU Unisoc T616, Octa Core; 2.0GHz
Unisoc T606 Optional
GPU Mali-G57 MP1@850MHz
RAM/ROM 4+64GB / 8+128GB
LCD 5.7 inch; 720×1520; 400nits
Touch Screen 5 Point Touch
Support stylus
Camera Front: 5MP; Rear: 13MP
Flash light
Power and Battery 4000mAh; 3.8V (15.2Wh)
WWAN 4G LTE, 3G WCDMA, GSM
4G Fre: FDD_LTE B1/B2/B3/B5/B7/B8/B20; TDD_LTE B38/B39/B40/B41
WCDMA B1/B2/B5/B8; GSM B2/B3/B5/B8
GPS BDS, GPS, GLONASS
WIFI 802.11a/b/g/n/ac Wireless Internet; Wireless AP (Mobile AP); 2.4G, 5G
BLUETOOTH 5.0 Version
MIC Sensitivity: -32±2d; Output Impedance: 2.2kΩx1
Dual microphones: main microphone for sound pickup, secondary microphone for noise reduction
SPEAKER 8Ω 1.0 Watt
NFC 13.56 MHz
Sensor Light sensor, Magnetic sensor, Pressure sensor, G-sensor, Distance sensor, Gyroscope, Motor
Size 155×77.7×13.3mm
Weight 230±20g
Language Multi language
Interface In/Out Port Type-C *1 (OTG); SIM+TF Card or SIM Card Slot*2 (Dual card single standby)
Bottom pogopin*4
Button V+ -, Power, SOS, Scan, Customized Button
1D/2D Barcode Optional: NLS-N1 Optional
Accessories Box; Charger (5V 2A); Thimble; Wrist rope
Multi-Media (Hardware Decoding) Photo Viewer: BMP, JPG, GIF, PNG
Video Format: MEPG 1/2/4, H.263/H.264, RMVB, WMV/VC-1, MVC, AVS, MJPEG (UP TO 1080P)
Audio Format: MP3, WMA, WAV, OGG, FLAC, ALAC, APE, AAC, AC-3, DTS (need license)
Proof Degree IP68 Anti-dust & Waterproof, 1.5m Dropping Resistance
Certification UN38.3, MSDS, CE
Temperature Storage Temperature: -40°C to 60°C; Operation Temperature: -20°C to 55°C

Application Scenarios

🚑
Emergency Medical Services
🌧️
Outdoor Field Operations
🏪
Retail Mobile Checkout
🌿
Agricultural Data Collection
